Small pellets burner

Type:HF-15
Calorific value：130000(kcal)
Combustion fan:120W
Energy consumption：10-32KG/H
Product description: Small pellets burner
INQUIRY

Characteristic:

1. It burns wood pellets with diameter 6-8mm.It ensures an efficient andlow-emission combustion.

2. OKK Produced of high-grade stainless steel,it withstands temperatures up to 1200.The built-in CPU-controlled unit, automatic, cleaning system and internal auger manager the burner operation for optimum efficiency.

3. STB thermostat (option)

Technical Parameters:

name model	HF-3	HF-5	HF-10	HF-15
Power range(KW)	10-35	20-50	50-100	80-130
Calorific value(KCAL)	30000	50000	100000	130000
Combustion fan	45W	65W	90W	120W
Combustion fan	220v/50-60HZ	220v/50-60HZ	220v/50-60HZ	220v/50-60HZ
Burner	160mm	160mm	200mm	200mm
Burner furance	High temperature resistant stainless steel pipe
Burner cover	Galvanized sheet
Igniter	600W/220V/50HZ
Storage Size	400400700MM		550550800MM
Wooden pellets	Length:6-8mm		length:10-30mm
Capacity (kg)	50	50	100	100
Burner rate	above>=95%
Energy consumption	2-8KG/H	3-10KG/H	6-20KG/H	10-32KG/H
Heating area	180-350M2	350-500M2	500-800M2	900-1200M2
Feeding power	220W/0.52A/220V/50-60Hz
Control Mode	Control unit
Dimensions(mm)	320300550	330300550	350320580	380350650
Burner weight	23kg	24kg	27kg	30kg
The above parameters for technical improvement,if there is a change in the factory actual shall prevail.
